Informação do produto

Nebula é nosso leitor RFID compacto com Android 11. Com um processador Qualcomm Snapdragon™ 662 Octa-core, oferece desempenho perfeito. A funcionalidade RFID UHF integrada, impulsionada pelo chip Impinj E510, garante um alcance máximo de leitura de até 2,7 metros, simplificando o gerenciamento de estoque. A leitura opcional de código de barras e os recursos NFC aumentam sua versatilidade. Seu design robusto, incluindo vedação IP65 e testes rigorosos, garante durabilidade. Seja para inventário, rastreamento de ativos ou logística, este leitor RFID oferece eficiência e confiabilidade incomparáveis.

Features
Android 11	Qualcomm Snapdragon™ 662 Octa-core, 2.0 GHz
5.5" IPS Display	RAM+ROM: 3+32GB/4+64GB (Optional)
5200mAh Removable Battery	QC3.0 Quick Charge and RTC
Functions
Built-in UHF RFID (Impinj E510 Chip)	Barcode Scanning (Optional)
NFC	13MP Autofocus Camera
Wi-Fi 6-ready

Especificações

Características físicas

Dimensions	160.0 x 76.0 x 17.0 mm / 6.3 x 2.99 x 0.67 in.
Weight	297 g / 10.47 oz. (device with battery)
Display	5.5-inch high definition full display (18:9), IPS 1440 x 720
Battery	Removable main battery 5200mAh, support QC3.0 and RTC Standby: up to 490 hours (only main battery ; WiFi: up to 470h; 4G: up to 440h) Continuous use: over 12 hours (depending on user environment) Charging time: 2.5 hours (charge device by standard adaptor and USB cable)
Touch Panel	Multi-touch panel, gloves and wet hands supported
Notification	Sound, LED indicator, vibrator
Interfaces	USB Type-C, USB 3.1, OTG, extended thimble;
Card slot	1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
Audio	2 microphones，1 for noise cancellation；1 speaker；receiver
Keypad	1 power key, 2 scan keys, 2 volume keys
Sensors	Accelerometer sensor, light sensor, proximity sensor, gravity sensor



Comunicação

WLAN	Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dual-band, IPV4, IPV6, 5G PA Fast roaming: PMKID caching, 802.11r, OKC Operating Channels: 2.4G(channel 1~13), 5G(channel36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132, 136,140,144,149,153,157,161,165), Depends on local regulations Security and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK—EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS,PEAP-GTC,etc
WWAN (Europe, Asia)	2G: 850/900/1800/1900 MHz 2G: 850/900/1800/1900 MHz       WCDMA: 850/900/1900/2100MHz       TD-SCDMA: A/F(B34/B39) 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41
WWAN (America)	2G: 850/900/1800/1900 MHz 3G: 850/900/1900/2100 MHz 4G: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38
Bluetooth	Bluetooth 5.1
Vo-LTE	Support Vo-LTE HD video voice call
GNSS	GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna



Ambiente em Desenvolvimento

Operating System	Android 11 / 13; GMS, 90-day security updates, Android Enterprise Recommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported
SDK	Software Development Kit
Language	Java
Tool	Eclipse / Android Studio



Desempenho

CPU	Qualcomm Snapdragon™ 662 Octa-core, 2.0 GHz
RAM+ROM	3 GB + 32 GB / 4 GB + 64 GB
Expansion	Supports up to 128 GB Micro SD card



Ambiente do usuário

Operating Temp.	-4°F to 122°F / -20 ℃ to +50 ℃
Storage Temp.	-40°F to 158°F / -40 ℃ to +70 ℃
Humidity	5% RH - 95% RH non condensing
Drop Specification	Multiple 1.8 m / 5.91 ft. drops (at least 20 times) to the concrete across the operating temperature range Multiple 2.4 m / 7.87 ft. drops (at least 20 times) to the concrete after installed rubber boot
Tumble Specification	1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing	IP65 per IEC sealing specifications
ESD	±15 KV air discharge, ±8 KV conductive discharge



Leitura de código de barras

2D Scanner	Zebra: SE4710/SE2100; Honeywell: N6603; E3200; IA166S; CM60
1D Symbologies	UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies	PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.
Note	*This function is optional



RFID UHF

Engine	CM-5N module based on Impinj E510
Frequency	865-868MHz / 920-925MHz / 902-928MHz
Protocol	EPC C1 GEN2 / ISO18000-6C
Antenna	Circular polarization (-5 dBi)
Power	1W (+19dBm to +30dBm adjustable)
Max Read Range	2.4m (Impinj MR6 tag, size 70 x 15mm) 2.6m (Impinj M750 tag, size 70 x 15mm) 2.7m (Alien H3 Anti-Metal tag, size 130 x 42mm)
Note	* Ranges are measured in the open outdoors and low interference environment, and rate is measured in a laboratory low interference environment, they are affected by tags and environment. * built-in UHF version does not support pistol



Câmera

Camera

Rear 13MP Autofocus with flash



NFC

Frequency	13.56 MHz
Protocol	ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips	M1 card (S50, S70), CPU card, NFC tags, etc.
Range	2-4 cm



Acessórios opcionais

Accessories

Wrist Strap; Rubber Bumper; Charging Cradle
