Microcosm - Fixed RFID Reader (Android 11)
Android 11 OS, Multiple Interfaces, More Powerful UHF RFID Performance
Product Information
Microcosm is a powerful, new fixed RFID reader designed for high-performance. It boasts a fast 2.0 GHz quad-core CPU and runs on the Android 11 operating system, enabling smooth and efficient data processing. Equipped with either the Impinj E710 or R2000 chip, the C500 delivers exceptional UHF performance for reliable tag reading. For flexible connectivity, the reader integrates RS232, RJ45, and HDMI interfaces. Additionally, the C500 supports a variety of power supplies including DC, POE, and POE+. This versatility makes the C500 ideal for demanding applications in warehousing, asset management, libraries, production lines, medical storage, unmanned retail, and more.
| Features | |
| UHF RFID (Impinj E710/R2000 Chip) | DC / POE / POE+ Power Supply |
| Supports RS232/RJ45/HDMI | Optional 4-Port or 8-Port |
| Android 11 | Linux OS (In Development) |
| Functions | |
| Jewelry Monitoring | Vending Machines |
| Intelligent Manufacture | Archives and Library Management |
| Inventory Management | Clothing and Footwear Retail |
Specifications
Physical Characteristics
| Dimensions | 247 x 151 x 35mm / 9.72 x 5.94 x 1.38in |
| Weight | 1000g / 35.27oz (Host Only) |
| Material | Aluminum Alloy |
| Input Voltage | DC 10V – 24V |
| Standby Current | < 140mA |
| Comm Interface | 1 x RS-232 ，1 x RJ45，1 x USB Host，1 x USB Device |
| GPIO | 4 x input optocouplers, 4 x output optocouplers, with isolation, 1 x wiegand |
| Baud Rate | 115200bps |
| Cooling Mode | Air Cooling |
| Work Current | 600mA +/-5% @ DC 24 V Input |
| Display Interface | HDMI Type A, supports 720p HD video output |
Communication
| Ethernet interface | 10/100 Base-T Ethernet (RJ45) |
| WLAN | IEEE802.11 b/g/n, 2.4G |
| Bluetooth | Bluetooth 4.0 |
Developing Environment
| Operating System | Android 11 |
| SDK | Software Development Kit |
| Language | Java |
| Tool | Eclipse / Android Studio |
Performance
| CPU | Quad - Core 2.0GHz |
| RAM+ROM | 2GB + 16GB |
User Environment
| Operating Temp. | -25°C to 65 °C / -13℉ to 149℉ |
| Storage Temp. | -40°C to 85°C / -40℉ to 185℉ |
| Humidity | 10% - 95% |
UHF RFID
| Engine | Based on Impinj E710 / Impinj Indy R2000 |
| Frequency | 865-868MHz / 920-925MHz / 902-928MHz |
| Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| Antenna | Support multiple antennas, such as 6dBic, 9dBic, etc. |
| Power | DC (24V)、POE (802.3af 13W)、POE+ (802.3at 25.5W) |
| Output Power | 1W (30dBm, support +5~+30dBm adjustable, POE / DC power supply) Optional 2W (33dBm, support +10~+33dBm adjustable, for Latin America, etc., POE+ / DC power supply) |
| Output Power Precision | +/- 1dB |
| Output Power Flatness | +/- 0.2dB |
| Receive Sensitivity | < -84dBm |
| RSSI | Support |
| Ambient Temp Monitor | Support |
| Fastest Read Rate | Up to 950 tags/s |
| Antenna Detector | Support |
| Antenna Port | 4 / 8 Channel 50Ω RF Connector RP-TNC Female |
